In the never ending debate regarding who makes a better reloading press, most are argued by colour. The big three are the green machines of RBCS, Hornady’s red equipment and the focus of this installment of TPF, the blue of Dillon Precision. Do not let the title fool you as it is a reference to the detractors as well as the supporters of Dillon products, who would be adamant that you, “Do or do not drink the blue Kool-Aid.” Aka, using Dillon’s presses.
As the title and opening lines suggest, Dillon Precision Products are normally painted in a blue colour which sets them as a recognizable alternative to the other press manufacturers. TPF has had some experience with progressive presses from other manufacturers, and has loaded several tens of thousands of rounds on single stage presses, to turret presses, to progressive presses. This would be our first foray into “Blue”. We selected a Dillon XL650 progressive press, as it is considered to be the staple flagship of the Dillon progressive press line. We also decided initially to use .40 S&W as the loading calibre as it is the “bastardized” calibre that usually incorporates parts from both a 9mm and a .45ACP setup, and causes the most headaches for reloaders.
The Dillon XL650 as tested with casefeeder, powdercheck, and roller handle options
The setup for reviewing:
- Dillon XL650 progressive press (MSRP $589.95 USD)
- 1 primer system with large and small priming parts (appropriate size installed).
- 1 large and one small primer pick-up tube.
- low primer alarm
- 1 loaded cartridge bin
- 1 set of standard Allen wrenches
- 1 toolhead
- 1 powder measure with standard large and small powder bars (small bar installed).
- 1 powder die
- 1 caliber conversion kit – installed
- Dillon .40 S&W die set (MSRP $67.95 USD)
- Dillon Roller handle (MSRP $47.95 USD)
- Dillon Case feeder (large pistol casefeed plate) (MSRP $239.95USD)
- Dillon Powder check (MSRP $70.95 USD)
This time around we are going to change it up a bit and go right to the cons of the Dillon XL650. The reasoning is simple, the two biggest negatives that are outstanding are very important ones that would prevent someone from purchasing this press. We at TPF can sense the pro-Dillon group gnashing their teeth and cursing us for stating this right up front, but please bear with us. These reasons would prevent someone from being able to utilize a Dillon XL650 period, regardless if they wanted one, it is that important to understand.
The first thing that anyone needs to realize is that the Dillon is a large, tall press which towers roughly 81cm (32″) above the mounting surface. That is without the case feeder system feeding/mounting requirements and the optional strong mount component, which add in 16cm (6.5″) and 21cm (8.5″) respectively and with clearance requirements . Most benches and tables are 0.9m (36″) high, when you add in the additional 1.2m (47″) including assembly/disassembly clearance, you are just a 9mm case short of 2.1m (84″). For many basements in older homes this is a very tall press indeed. especially with ductwork and other stuff which can severely limit ceiling height. However as tested without the strong mount option, this XL650 measured 89cm(35″) above the mounting surface and TPF had no issues at the review location.
Other than the height of the unit, the main drawback of the Dillon XL 650 is the initial starting cost. Many people tend to overlook reloading press costs when talking about reloading, but not everyone will have the funds available to acquire a Dillon XL650 without some planning and budgeting. The base unit has a hefty price tag of nearly $590 USD at the time of this review. What if the reloader wants the ability to interchange calibres fast, have fast primer fillers, storage racks for tools and calibre set-ups, etc…? Dillon can provide the components and tools to make it happen, but for a price. When you add in the listed add-ons just solely for this review, the press costs adds up to in excess of $1000 USD. And that is not even the extent of the optional components and add-ones to enhance the XL650 to it’s fullest such as:
There are many more factory options available
- Strong Mount (550/650) (MSRP $50.95 USD)
- Low Powder Sensor (MSRP $42.95 USD)*
- Bullet Tray (MSRP $44.95 USD)
- Toolholder w/Wrench Set (MSRP $30.95 USD)
- Dillon Pistol Three Die Set (MSRP $67.95 USD)*
- Additional Case Feed Plates (MSRP $39.95 USD)
- Machine Maintenance Kit (MSRP $41.95 USD)
- Spare Parts Kit (MSRP $27.95 USD)
- Dust Cover (MSRP $42.95USD)
- Toolhead Stand (MSRP $22.95)
- For additional calibres (*optional)
- Toolhead (MSRP $31.95 USD)
- Calibre Conversion Kit (MSRP $79.95 USD)
- Powder Die (MSRP $12.95 USD)
- Powder Measure (MSRP $84.95 USD)
If you wanted a fully kitted-out Dillon machine with two (2) complete calibres such as 9mm and .45 ACP, your total would be in excess of $1650 USD. That is some serious expenditure for the majority of casual firearms owners. If you are wanting Magnum rifle and exotic calibres, the prices are even higher for those component parts. Space claim, and cost. These are the TWO major obstacles that need to be overcome before acquiring a Dillon XL650 progressive press. That is it. So if you have the ability to fit and afford the Dillon please keep reading on.
While there are a few little quirks and stickling points regarding the press and its usage, they are not reasons for avoiding the Dillon.
Looking at the initial design and the quality, fit and finish of the press when assembled, it is nearly flawless. The main press frame components are cast clean with no flash and a beautiful, even powder coated blue finish. The alloy cast parts are neat and clean as well with minimal parting lines displayed and no burrs or sharp edges anywhere that can be touched. Machined portions are excellent with good surface finished and minimal tooling marks visible. The entire design uses hex head bolts, or hex head cap screws when threaded components are required, the remainder is attached and assembled with E-Clips and various snap rings. A very well engineered design, with good hardware control. Items which are not powder coated, or aluminum are plated to minimize corrosion, which is another added plus. Which brings us to another item. Dillon’s “No BS Warranty!” Every single option and add-on is as well made as the press assembly itself and Dillon stands behind it’s mechanical components for life. Yes for life. You have something break, bend, or otherwise get mauled? Call Dillon, get it replaced.
The instruction/installation manual is extensive and includes all Dillon options for mounting and installation. Loaded with visual images and clear precise methods, the manual includes full part lists and detailed component breakdowns. Bolting and mounting is as simple as can be expected for a progressive press. Set-up of the press is clear and pretty much straight forward thank to the illustrative and comprehensive instruction manual. The manual progresses through the setup of any calibre in an orderly fashion, starting with the re-sizing and decapping, moving on to the primer feed system and powder measure and finally with the seating and crimping portion of the press.
The usage of retaining pins for case keeping at the five (5) indexed positions are very accessible and allow for a simple method of removing/reinserting cases in the middle of the reloading process. A very simple and smart idea. The finished bullet chute works extremely well at delivering the completed round to whatever size of tray you wish to use for the final catch basin.
Rotating clockwise for operation. The ejection chute runs along the case feed slider
The fit and finish are very, very good
The slider bar powder system is a tried and true design that has been used for many decades in powder dispensing systems. In the case of the Dillon, the bar has an adjustable orifice which allows for the volumetric control of powder to be dispensed on each operation. With this come the first little quirk as setting your desired volume of powder is a very touchy operation due to the simple hex head bolt system. There are numerous aftermarket components or replacements to this adjustment bolt that allow for a finer control over the orifice size. That being said; once the system is setup, it stays consistent and never shifted during our testing.
With the system setup, TPF churned out over one thousand rounds of ammo in a little under three (3) hours. Please remember that this was our initial setup and test run of this press and we observed all aspects of the press to determine the function and traits of the press. Our biggest bottleneck in reloading? Filling primer tubes. Once we had gotten the system all setup TPF decided to try the quick change aspect of the system and acquired a Calibre Conversion kit, dies, toolhead, etc… for 9mm. Here is where the strength of the Dillon truly shines with the ease of swapping full calibre arrangements back and forth, in under 15 minutes with pre-set toolheads. The new tool head had the powder measure, dies already setup and locked in place, with the only requirements being to remove a few set screws, change the brass plate holder and the pins and VIOLA! The press is ready to go, only for a different calibre. Except for the bending of an Allen-key trying to remove a very secure factory installed insert, the changeover worked very well. We are assuming that this issue will not give us any issues in the future as anti-seize compound was added to the offending thread during the calibre conversion. As long as the primer size remains the same, this is an extremely easy method for swapping calibres.
The first batch of reloading mid-production
With the new 9mm setup, we quickly produced in excess of 1500 completed rounds of ammunition. By quickly we should mention that it was in the same timeframe as previously, three (3) hours.
The ONE stickling point…
The positive indexing primer feed system
The primer system…. This is the only truly detraction that the XL650 has regarding it’s operation. Primers are ejected from the De-Capping die into a small removable tray and occasionally the primers will bounce out of the tray and onto the floor, regardless on the manufacture and design of the de-capping pin. So keep a broom handy and watch your step if you hear the primers fall out and empty your spent primer collection tray on a regular basis. The real issue is when installing new primers into cases. Specifically if there is no case to install a primer into… The primer feed system is a positive indexing system so it feeds a new primer with every pull of the handle and if it doesn’t use the primer, well… When the primer loading system cycles and fails to install a primer into a case due to the absences of the case, that primer continues on it’s way around in the primer carousel until it gets dropped. This occurs before the next primer tries to take up the same space. That unused primer then takes a trip off what is known as the Dillon Ski-Ramp. TPF installed the 9mm conversion kit and then heard something hitting the wall with nearly every press for a couple pulls of the handle. Turns out to have been live primers launching themselves off a small sloped path located at the front underside of the main ram platform. This shallow, low ridged ramp, actually managed to stop 1 in 5 live primers during our setup of the 9mm, so if you are doing any setup, do it with an empty primer system.
Spent Primer collection tray and round discharge chute
The Ski-Ramp for launching unused primers
The Options: As reviewed
- Roller Handle – Very well made, and more comfortable to use that the original handle, but not a requirement for an efficient XL650 setup.
The roller handle… A nice option, but not necessary
- Powder Check – An excellent and simple design. Easy to use and to move from one calibre set-up to another. A good addition.
- Case Feeder – The unit itself is quiet, very quiet. The low and high speed options are excellent and the steel guide panel is an excellent choice to adjust for the feed wheel edge. Be aware that these case feeders are not meant to hold more than a couple hundred cases at a time due to mass, the motor/clutch can be overloaded. A necessity for any volume reloading.
These last couple items are more of a general commentary on what Dillon can du to improve their product, or at least include to make their customers even more satisfied.
- Primer de-cap tray and the ‘Ski Jump’ – add in a small piece of foam in the de-capped collection tray or increase it’s depth to prevent bounce outs. Change the design of the ski-ramp to have larger walls or into a removable barrier that stops unused primers from launching across the room. There are already aftermarket option out here for this.
- A small tube of lubrication- The greased ramps work well, if a bit messy as if you need to adjust you will come into contact with at least one of these sliding surfaces. That way Dillon can indicate what types of grease to you and frequency of re-application.
- Locator arrow – Station #1 should have an arrow on the locator as it can go in backwards, where it will not work. Ask TPF how they know this…
- The ratchet system – Another company builds a bearing drop-in system that makes the ratchet action as smooth as silk.
- Mounting hardware – It’s $1 worth of bolts, washers, and nuts. Include it with the basic set.
- Spare parts kit – Have some of the more commonly broken, smaller items included as spares, such as plastic nuts, pins, etc…
Mounting requires a bit of overhang to clear the armature linkage. The Strongmount option solves this
We have drank the Blue Kool-Aid and have found it a very satisfying… Expensive and not perfect, but a very capable machine for those reloaders who want to maximize their rate of loading with the ability to have multi-calibre stations available to change on a whim. For the shooter who only reloads for one single calibre, there may be other brands which will preform the same for a more affordable price point. However! if you load for two or more (2+) calibres and value your time for setting up a press and appreciate the convenience of fully setup, easily swappable calibre conversions, the Dillon XL650 may be indeed the best flavour of kool-aid for you!
With a base MSRP of $589.95 USD, Dillon Precision’s XL650 reloading press is a solid addition to a reloader’s repertoire of equipment, albeit not inexpensive. Dillon Precision products are available online as well as at physical stores such as the Montreal Firearms Recreation Centre (CRAFM), in Lachine, Quebec. As always, to readers of TPF, the final decision of this product is up to you. Do you think that it falls under the category of Tactical, Practical, or Fantastical?
Some additional images:
The case feeder advancing lever and ramp
The powder check works by lifting the alarm up via the ram/shell plate
If the powder in a case does not bring the groove to the right point, the alarm stub gets depressed
Sliding volumetric powder dispensing coupled is very consistent when set
Quieter than many, the casefeeder worked flawlessly
Lots of clearance around the press for accessing brass, but be wary of the greased surfaces
